Winstar has added 2 new TFT LCD displays to its product range. The 1.54″ 240×240 IPS TFT Square LCD Display is a TFT-LCD with a 1.54-inch diagonal square screen and a resolution of 240×240 pixels. The 15.6″ 1920×1080 eDP Interface TFT LCD Display is a 1920×1080 high-resolution eDP-interface TFT display with a 15.6-inch diagonal size. More detailed information about both displays can be found below.
1.54″ 240×240 IPS TFT Square LCD Display
WF0154ATAAA4DSN0 and WF0154ASAAA4DSN0 are two TFT-LCD modules with a 1.54-inch square screen and a resolution of 240×240 pixels. These two TFT displays are built-in with ST7789T3-G4-1 driver IC that can communicate via SPI interfaces.
The modules adopt an IPS panel to present wider viewing angles of Left: 80/ Right: 80/ Up: 80/ Down: 80 degrees (typical value). Besides, they have 900:1 high contrast ratio and a full-black background when the display or pixel is off. While WF0154ATAAA4DSN0 has 380 nits brightness (typical value), WF0154ASAAA4DSN0 possesses a high brightness of 850 nits (typical value).
These two 1.54-inch TFT-LCDs are suitable for applications such as wireless speakers, microphones, coffee machines, personal pulse oximeters, etc.
Model No.:WF0154ATAAA4DSN0
- Size: 1.54-inch
- Dot Matrix: 240 × 240 dots
- Module Dimensions: 31.52 × 33.72 × 1.94 mm
- Active Area: 27.72 × 27.72 mm
- Viewing Angles: 80/80/80/80 (IPS)
- Driver IC: ST7789T3-G4-1
- Interface:SPI
- Touch Panel: Without Touch Panel
- Surface: Anti-Glare
- Brightness: 380 cd/m2
- Operating Temperature: -10~+60℃
Model No.:WF0154ASAAA4DSN0
- Size: 1.54-inch
- Dot Matrix: 240 × 240 dots
- Module Dimensions: 31.52 × 33.72 × 1.94 mm
- Active Area: 27.72 × 27.72 mm
- Viewing Angles: 80/80/80/80 (IPS)
- Driver IC: ST7789T3-G4-1
- Interface:SPI
- Touch Panel: Without Touch Panel
- Surface: Anti-Glare
- Brightness: 850 cd/m2
- Operating Temperature: -10~+60℃
15.6″ 1920×1080 eDP Interface TFT LCD Display
WF1560BSYAA5ENN0 and WF1560BTYAA5ENN0 are 1.56-inch TFT LCDs with a high resolution of 1920×1080 pixels. These two display modules are built-in with TC2055G driver IC and support eDP interfaces. The eDP (Embedded Display Port) interface has been widely used in laptops, tablets, mobile phones, and other fields integrating display panels and image processors. The eDP communication protocol has the characteristics of high bandwidth, good integration, and simple design of related products.
WF1560BTYAA5ENN0 has a brightness of 500 nits (typical value), and WF1560BSYAA5ENN0 possesses a high brightness of 1000 nits (typical value). They both feature a contrast ratio of 1,500:1 (typical value). These two 15.6-inch eDP display modules are suited for various applications, including industrial control equipment, test instruments, reverse vending machines (RVM), and point-of-sale (POS) Systems.
Model No.:WF1560BTYAA5ENN0
- Size:15.6-inch
- Dot Matrix:1920 × 1080 dots
- Module Dimensions: 360.0 × 212.3 × 9.0 mm
- Active Area: 344.16 × 193.59 mm
- Viewing Angles: 80/80/80/80 (IPS)
- Driver IC: TC2055G
- Interface: eDP
- Touch Panel: Without Touch Panel
- Surface: Anti-Glare
- Brightness: 500 cd/m2
- Operating Temperature: -20~+70℃
Model No.:WF1560BSYAA5ENN0
- Size: 15.6-inch
- Dot Matrix: 1920 × 1080 dots
- Module Dimensions: 360.0 × 212.3 × 9.0 mm
- Active Area: 344.16 × 193.59 mm
- Viewing Angles: 80/80/80/80 (IPS)
- Driver IC: TC2055G
- Interface: eDP
- Touch Panel: Without Touch Panel
- Surface: Anti-Glare
- Brightness: 1000 cd/m2
- Operating Temperature: -20~+70℃
If you want more information or if you have any questions, please contact Nijkerk Electronics!
